Especificaciones:
Dimensions: 443 x 43 x 221 mm
Weight:
Rack-Mount Brackets Excluded:2.80 kg
Rack-Mount Brackets Included: 2.89 kg
Networking Interfaces:
(16) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management Interface: Ethernet In-Band
Total Non-Blocking Throughput: 18 Gbps
Switching Capacity: 36 Gbps
Forwarding Rate: 26.78 Mpps
MAC Address Table: 16384
Maximum Aggregations: 6
Monitoring Sessions: 1
Maximum VLANs: 255
Power Method: 100-240VAC/50-60 Hz, Universal Input
Power Supply: AC/DC, Internal, 150W DC
Max. Power Consumption:
Including PoE Output: 150W
Excluding PoE Output: 28W
LEDs Per Port:
RJ45 Data: PoE, Speed/Link/Activity
Ports SFP Data Ports: Speed/Link/Activity
Sound Level:
Fan Level: 0 -> 1.7 dBr
Fan Level: 1, 2, 3 -> 10.8 dBr
ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
Shock and Vibration: ETSI300-019-1.4 Standard
Operating Temperature: -5 to 40° C (23 to 104° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC
