24-Port Gigabit PoE Smart Switch with 4 SFP ports (12 x PoE ports)

Number of 10/100/1000BASE-TX ports

• DGS-1210-24P - 24 ports

Number of SFP ports

• DGS-1210-24P - 4 ports

Number of Combo 1000Base-T/SFP ports

• DGS-1210-48 - 4 ports

PoE Supported Models (Standard(s)/Number of Ports/Maximum Power Budget)

• DGS-1210-24P (802.3af/802.3at/12 ports/85W)

Performance

Switch Capacity

• DGS-1210-24P - 56 Gbps

64-Byte Packet Forwarding Rate

• DGS-1210-24P - 41.7 Mpps

MAC Address Table Size

•
• DGS-1210-48 - 1 fan

Heat Dissipation

• DGS-1210-24P - BTU per hour

Temperature

• Operating: -5° to 50°C (23° to 112°F)
• Storage: -20° to 70°C (-4° to 158°F )

Humidity

• Operating: 0% ~ 95% non-condensing
• Storage: 0% ~ 95% non-condensing

Certification

• CE Class A

Safety

• cUL, LVD

Software Feature

L2 Features

• MAC Address Table: 16K
• Flow Control
  • 802.3x Flow Control
  • HOL Blocking Prevention
• Jumbo Frame up to 13,000 Bytes
• IGMP Snooping
  • IGMP v1/v2 Snooping
  • IGMP Snooping v3 Awareness
  • Supports 256 IGMP groups
  • Supports at least 64 static multicast addresses
  • IGMP per VLAN
  • Supports IGMP Snooping Querier
• MLD Snooping1
  • Supports MLD v1/v2 awareness
  • Supports 256 groups
  • Fast Leave
• Spanning Tree Protocol
  • 802.1D STP
  • 802.1w RSTP
• Loopback Detection
• 802.3ad Link Aggregation
  • DGS-1210-10P: Max. 5 groups per device/8 ports per group
  • DGS-1210-20: Max. 10 groups per device/8 ports per group
  • DGS-1210-28/28P: Max. 14 groups per device/8 ports per group
  • DGS-1210-52: Max. 26 groups per device/8 ports per group
  • DGS-1210-16/24/48: Max. 8 groups per device/8 ports per group
• Port Mirroring
  • One-to-One, Many-to-One
  • Supports Mirroring for Tx/Rx/Both
• Multicast Filtering
  • Forwards all unregistered groups
  • Filters all unregistered groups
  • LLDP, LLDP-MED

VLAN

• 802.1Q Tagged VLAN
• VLAN Group
  • Max. 256 static VLAN groups
  • Max. 4094 VIDs
• Management VLAN
• Asymmetric VLAN
• Auto Voice VLAN
  • Max. 10 user-defined OUI
  • Max. 8 default OUI
• Auto Surveillance VLAN

Quality of Service (QoS)

• 802.1p Quality of Service
• Queue Handling
  • Strict
  • Weighted Round Robin (WRR)
• 8 queues per port
• Bandwidth Control
  • Port-based (Ingress/Egress, min. granularity for 10/100/1000Base-T ports is 15 Kb/s)
• CoS based on
  • 802.1p Priority Queues
  • DSCP
  • ToS
  • TCP/UDP port number
  • IPv6 traffic class1

Access Control List (ACL)

• Max. 50 profiles
• Max. 200 rules shared by profiles
• Single or multiple ports (each rule)
• ACL based on
  • MAC Address
  • IPv4 Address (ICMP/IGMP/TCP/UDP)
  • IPv6 Address (ICMP/TCP/UDP)1
  • 802.1p
  • DSCP
  • Ether type
  • IPv6 traffic class1
• ACL Actions
  • Permit
  • Deny

Security

• Port Security
  • Supports up to 64 MAC addresses per port
• Broadcast/Multicast/Unicast Storm Control
• Static MAC
• D-Link Safeguard Engine
• DHCP Server Screening
• Trusted Host
• ARP Spoofing Prevention
  • Max. 64 entries
• SSL
  • Supports v1/v2/v3
  • Supports IPv4/IPv6
• Traffic Segmentation
• Smart Binding1
  • Discover connected devices and click to bind
  • ARP Packet Inspection: 512 entries
  • IP Packet Inspection: 128 entries
  • Supports DHCP Snooping

AAA

• 802.1X Port-based Authentication
  • Supports RADIUS Server
  • Supports EAP, OTP, TLS, TTLS, PEAP

OAM

• Cable Diagnostics
• Factory Reset

MIB

• 1213 MIB II
• 1493 Bridge MIB
• 1907 SNMP v2 MIB
• 1215 Trap Convention MIB
• 2233 Interface Group MIB
• D-Link Private MIB
• Power-Ethernet MIB
• LLDP MIB
• D-Link ZoneDefense MIB1

RFC Standard Compliance

• RFC 783 TFTP
• RFC 854 Telnet Server
• RFC 951 BootP/DHCP Client
• RFC 1157 SNMP v1, v2, v3
• RFC 1213 MIB II, IF MIB
• RFC 1215 MIB Traps Convention
• RFC 1350 TFTP
• RFC 1493 Bridge MIB
• RFC 1542 BootP/DHCP Client
• RFC 1769 SNTP
• RFC 1901 SNMP v1, v2, v3
• RFC 1907 SNMP v2 MIB
• RFC 1908 SNMP v1, v2, v3
• RFC 2068 FCS
• RFC 2131 BootP/DHCP Client
• RFC 2138 RADIUS Authentication
• RFC 2139 RADIUS Authentication
• RFC 2233 Interface Group MIB
• RFC 2246 SSL
• RFC 2475
• RFC 2570 SNMP v1, v2, v3
• RFC 2575 SNMP v1, v2, v3
• RFC 2598 CoS
• RFC 2616 FCS
• RFC 2618 RADIUS Authentication
• RFC 2819 RMON v1
• RFC 2865 RADIUS Authentication
• RFC 3164 System Log
• RFC 3195 System Log
• RFC 3411-17 SNMP
• RFC 3621 Power Ethernet MIB

Management

• Multi-Language Web-based GUI
  • English (default)
  • Simplified Chinese1
  • Traditional Chinese1
  • French1
  • German1
  • Italian1
  • Japanese1
  • Portuguese1
  • Russian1
  • Spanish1
• SmartConsole Utility2
• Simplified CLI
• Telnet Server
• TFTP Client
• IPv6 Neighbor Discovery
• Configurable MDI/MDIX
• SNMP
  • Supports v1, v2, v3
• SNMP Trap
• System Log
  • Max. 500 log entries
• BootP/DHCP Client
• D-Link Network Assistant support1
• SNTP
• ICMPv6
• IPv4/v6 Dual Stack1
• DHCP Auto Configuration
• RMON v1

D-Link Green 3.0 Technology

• Power Saving by:
  • Link Status
  • Cable Length detection
  • LED or Port Shutoff
  • Port Standby mode
  • System Hibernation mode
  • Time-based PoE (PoE model only)
